Description
Brand: XOLORspace
Specifications:
Length of CAT-6 cable between Rx and TX: up to 120 meters
HDMI Input/output: 4k/1080p/1080i/720p/576p/576i/480p/480i
Max bandwidth: 340MHz
Max baud rate: 3x3.4Gbps
Input video signal: 0.5~1.5Volts p-p
Output DDC signal: 5Volts p-p (TTL)
Input HDMI cable distance: max. 10m AWG26 HDMI standard cable
Output HDMI cable distance: max. 10m AWG26 HDMI standard cable
TX Max working current: 300mA
RX Max working current: 300mA
Power adapter Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Dimension (L x W x H): 60x56x19 (mm)
TX Weight: 49g
RX Weight: 49g
Connection and operation:
1. Connect one HDMI cable between source device and TX Extender, the max cable distance is 10 meters;
2. Connect one HDMI cable between display device and RX Extender, the max cable distance is 10 meters;
3. Connect single CAT6(recommended) cables instead of HDMI cables between TX and RX Extender, the max cable distance is 120 meters;
4. Connect 5V power supply to the TX and RX;
5. EDID button: The button can support the switch of EDID between 1080P and 4K. (Default 4K).
• XOLORspace EX120 carries transparent transmission of UHD HDMI over CAT6 up to 120m with no delay, no compression
• TX is with HDMI loop out, connecting to a local display at the same time. While local display and the distant display are with different resolution, it will down to the lower to both displays.
• With 3.5mm audio extractor, connecting to a speaker or earphone.
• With EDID setting switching 4K and 1080p
• Portable size, easier to carry or hide from furniture.
Specifications:
Length of CAT-6 cable between Rx and TX: up to 120 meters
HDMI Input/output: 4k/1080p/1080i/720p/576p/576i/480p/480i
Max bandwidth: 340MHz
Max baud rate: 3x3.4Gbps
Input video signal: 0.5~1.5Volts p-p
Output DDC signal: 5Volts p-p (TTL)
Input HDMI cable distance: max. 10m AWG26 HDMI standard cable
Output HDMI cable distance: max. 10m AWG26 HDMI standard cable
TX Max working current: 300mA
RX Max working current: 300mA
Power adapter Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Dimension (L x W x H): 60x56x19 (mm)
TX Weight: 49g
RX Weight: 49g
Connection and operation:
1. Connect one HDMI cable between source device and TX Extender, the max cable distance is 10 meters;
2. Connect one HDMI cable between display device and RX Extender, the max cable distance is 10 meters;
3. Connect single CAT6(recommended) cables instead of HDMI cables between TX and RX Extender, the max cable distance is 120 meters;
4. Connect 5V power supply to the TX and RX;
5. EDID button: The button can support the switch of EDID between 1080P and 4K. (Default 4K).
• XOLORspace EX120 carries transparent transmission of UHD HDMI over CAT6 up to 120m with no delay, no compression
• TX is with HDMI loop out, connecting to a local display at the same time. While local display and the distant display are with different resolution, it will down to the lower to both displays.
• With 3.5mm audio extractor, connecting to a speaker or earphone.
• With EDID setting switching 4K and 1080p
• Portable size, easier to carry or hide from furniture.
