Description
Brand: UHPPOTE
• Model: CYLD05F4H-E100
• Rated voltage Un: 5V
• Maximum continuous running voltage Uc: 6V
• Case Meterial: Aluminum shield
• Interface method: RJ45
Overview:
This surge protector refer to GB/2004/IEC61643 - T18802.21 2006 strikes design.
Usage environment:
Temperature: -40?~70? / -40?~158?
Relative humidity: ?95%
Atmospheric pressure: 70kPa~106kPa
Technical indicators:
Model: CYLD05F4H-E100
Rated voltage Un: 5V
Maximum continuous running voltage Uc: 6V
Insulation resistance M?: ?0.4M?
Insertion loss dB: ?0.5dB
Proximal crosstalk: ?60dB(PASS)
Bandwidth FG: (0.3-100)M
Transmission rate VS: 100M
Response time Ta: ?1ns
Protection class: IP20
Demensions: 80x25x25mm / 3.1"x1"x1"
Case Meterial: Aluminum shield
Lines of protection: 2 Pairs (1-2,3-6)
Interface method: RJ45
Installation instructions:
Protectors access system before, first check grounding resistance, generating should comply with the requirements specification
Protectors by protection equipment front-end, access to reliable connect
Protectors as soon as possible the grounding lines connected to protect grounding busbar.
Precautions:
Protectors have input (IN), output(OUT) mark, output terminal and protected, don't connect the device to connect. Otherwise it will cause the protector the damage, the equipment can be protected.
Due to plug sockets connected factors such as loss of poor should be caused by increased connected or replace protector.
User shall not take remove protector of each place fasteners, lest cause damage, affect the normal work.
Package:
1 x Surge protector
• Model: CYLD05F4H-E100
• Rated voltage Un: 5V
• Maximum continuous running voltage Uc: 6V
• Case Meterial: Aluminum shield
• Interface method: RJ45
