Brand: StarTech.com

Add four USB 3.0 ports with two independent channels, LP/SATA power, and charging support to your PC through a PCI Express slot. The PEXUSB3S42V 4-port PCI Express USB 3.0 card lets you add four USB 3.0 ports with two dedicated 5 Gbps channels to your PCIe x4-enabled PC. This independent port architecture improves USB 3.0 performance by transferring data on two individual channels to your computer, giving you faster file transfers. When multiple devices are connected, traditional single bus USB 3.0 cards share your maximum bandwidth between all ports. By employing a second host controller chip set, the transmission channel is shared across two ports rather than four. Dedicating up to 5 Gbps for each set of two ports reduces performance bottlenecks, and effectively doubles your total available to bandwidth to 10 Gbps. Enhanced with UASP support (USB attached SCSI Protocol), this USB 3.0 controller performs up to 70% faster than conventional USB 3.0 when paired with a UASP supported enclosure (Note: UASP requires a compatible operating system). using a more efficient Protocol than the traditional USB bot (bulk-only transport), UASP technology optimizes transfers by allowing multiple commands to be processed simultaneously, significantly increasing transfer speeds for less wait time on data transfers. For high-power USB devices, this PCIe USB 3.0 card includes an optional SATA or LP4 power connector to connect to your system power supply and deliver up to 900mA of power per port to USB 3.0 bus-powered devices (500mA for USB 2.0). the USB 3.0 card also supports USB battery charging specification 1.2 (Apple mode only), letting you charge compatible Apple devices (I phones and iPad) faster than a standard USB 3.0 port.

Features:

• INCREASED PRODUCTIVITY: The USB 3.0 expansion card adds four USB 3.0 ports with two dedicated 5 Gbps channels to your system. This independent port architecture improves USB 3.0 performance.
• ENHANCED WITH UASP SUPPORT: The USB 3.0 PCI express card adapter uses UASP technology
• UASP technology optimizes transfers by allowing multiple commands to be processed simultaneously.
• ADDED POWER CAPABILITIES: For high-power devices, this 4-port USB 3.0 PCIe card includes an optional SATA or LP4 power connector to deliver up to 900mA per port to USB 3.0 bus-powered devices.
• MAXIMUM COMPATIBILITY: The USB 3.0 PCIe card adapter supports USB Battery Charging Specification 1.2 (Apple Mode only). It is also backward compatible with existing USB 2.0 / 1.1 devices.

Product Details:

• Color: Black
• Size: 4.7" x 0.6" x 6.6"
• Model: PEXUSB3S42V
• Package Quantity: 1
