Brand: REVOTECH

Overview:<br>USB0503 PoE splitter is a new model: With RJ45 port and Micro USB Port. <br>It is an economical and practical PoE remote power equipment base on IEEE802.3af standard. It can separate the power and data via cable transmission.Proper matching use with poe switch or PSE injector which meet standard IEEE802.3af,Provides power and data at the same time for the terminal device does not support PoE. <br>PoE splitter, output voltage of 5V use with the power supply equipment, It helps to expand wireless city, Security monitoring and other poe practical place, and is not restricted by layout of power line.<br><br>Specifications:<br> Support international standard IEEE802.3 af;<br> POE port Support 10/100Mbps data transmission<br> PD support 44V - 57V voltage transmission, Automatically detects power supply from PSE power supply module <br> 5V/3A power output using Micro USB, the Micro USB port only for power-charging.<br> Support the isolation circuit protection, can effectively protect electrical equipment.<br> Support the short circuit, overvoltage protection, light load protection, Overload protection<br> 1500V high voltage isolation <br><br>Model: USB0503<br>Transfer Rate: 10/100Mbps<br>Power: Input 48V DC /0.6A, Output 5V/3A<br>Standard: IEEE802.3 af<br>TRNF: 1/2(+),3/6(-);4/5(+),7/8(-)<br>Interface Type: 1 Input RJ45 port, 1 output RJ45 port, 1 DC output?Micro USB?<br>Standard: IEEE 802.3 I, IEEE 802.3 u, IEEE 802.3 x, IEEE 802.3 af<br>LED: Yellow PoE lamp<br>Temperature: Work within -20~50°,Storage within -30~60°<br>Humidity: Work within 10%~90% (Non-condensing), Storage within 5%~95% (Non-condensing)<br>Dimension: 27.5cm x 2.8cm x 2.3cm<br>Weight: 0.05kg<br><br>Package Content:<br>1 x POE Splitter (USB0503)

Features:

• Support international standard IEEE802.3 af
• POE port support 10/100Mbps data transmission. Transfer Rate: 10/100Mbps, Standard: IEEE 802.3 I, IEEE 802.3 u, IEEE 802.3 x, IEEE 802.3 af.
• 5V/3A power output is using Micro USB, the Micro USB port only for power-charging.
• PD support 44V - 57V voltage transmission. Automatically detects power supply from PSE power supply module.
• Support the isolation circuit protection, can effectively protect electrical equipment
• Support the short circuit, overvoltage protection, 1500V high voltage isolation.
• POE splitter can separate the power and data via cable transmission. Proper matching use with POE switch or PSE injector which meet standard IEEE802.3af, provides power and data at the same time for the terminal device does not support PoE so that non-PoE devices can be powered over Ethernet.

Product Details:

• Color: 5V 3A USB0503
• Size: 5V 3A USB0503
• Model: USB0503
• Package Quantity: 1
