Features || 3" Voice Coil | 1200 Watts Peak Power Handling | Ferrite Magnetics | Precision Circular Wire Geometry | Die Cast Aluminum Chassis | Applications | The P Audio 15BM-1200CANEW is a high output wide bandwidth transducer. The 15BM-1200CA NEW is an upgraded design that features many of P Audio s new technologies & performance upgrades. The 15 inch (381mm) diameter piston will produce extremely high sound pressure levels at both low & mid band frequencies & is ideal for high level response in both live sound & recorded music venues. | The transducer has a rated bandwidth of 45Hz to 3500Hz. The transducer uses high energy ferrite magnetics to achieve a very high acoustic output to weight ratio. The 15BM-1200CA NEW has been optimized for use in two way or three way sound reinforcement systems. The 15BM-1200CA NEW employs a medium format 3 inch (76.2mm) diameter voice coil that provides an AES rated 300 watts of continuous power handling & a full 1200 watts of peak rated power handling when sufficient amplifier headroom is available. The 15BM-1200CA NEW utilizes P Audio s Auto Balanced Cooling (ABC) technology to not only improve transducer power handling & reliability but to also increase power compression performance by carefully balancing & directing airflow to critical areas. The voice coil design is a bobbin wound geometry w/P Audio's precision circular wire technology to insure high conversion efficiency. | The system suspension has been designed specifically for high linear displacement & extended low frequency response. The 15BM-1200CA NEW also features a single spider configuration that provides system reliability & mechanical control. The transducer chassis is a die cast aluminum design that insures a very high degree of structural integrity. || Nominal diameter : 381 mm/15 in | Power rating : 300 Watt(aes) | Nominal impedance : 8 ohms | Sensitivity : 97 dB | Frequency range : 45-3500 Hz | Chassis type : Cast aluminum | Magnet type : Ferrite | Magnet weight : 2.3 kg/81.4 oz | Voice coil diameter : 76.2 mm/3.0 in | Coil material : CCA-W | Former material : Glass fiber | Cone material : Paper | Surround material : Cloth | Suspension : Single | X-max : 3.4 mm/0.13 in | Gap depth : 10.0 mm/0.39 in | Voice coil winding width : 16.8 mm/0.66 in | Net Weight : 8.0 kg/17.6 lb | Packing Dimension WxDxH : 430 x 430 x 220 mm | Shipping Weight : 9.0 kg/19.8 lb || Small Signal Parameters || Re : 5.7Q | Fs : 48 Hz | Mms : 92.19 g/3.25 oz | Mmd : 77.81 g/2.74 oz | Qms : 5.39 | Qes : 0.43 | Qts....0.40 | Vas : 123.35 lt/4.36 ft | Bl : 19.19 Tm | Cms : 1.2e-04 m/N | Rms : 5.10 Ns/m | Le (at 1kHz) : 0.44 mH | Sd : 855 cm2

Features

• The P-Audio 15BM1200CA is a high-performance 15-inch woofer designed for professional audio applications. This woofer is optimized for use in two-way or three-way sound reinforcement systems and is ideal for high-output applications in live sound and recorded music venues.
• Specifications (1)
• Nominal Diameter : 15 inches (381 mm)
• Power Handling : AES Power: 300 watts
• Peak Power: 1200 watts
• Frequency Response : 45 Hz - 3500 Hz
• Impedance : 8 ohms
• Sensitivity : 97 dB
• Voice Coil Diameter : 3 inches (76.2 mm)
• Magnet Material : Ferrite
• Cone Material : Treated paper cone
• Chassis : Die-cast aluminum
• Specifications (2)
• Cooling Technology : Auto Balanced Cooling (ABC) for improved power handling and reliability
• Dimensions
• Overall Diameter : 16 inches (406 mm)
• Depth : 7 inches (178 mm)
• Weight : 22 lbs (10 kg)
• The P Audio 15BM-1200CA is a high output wide bandwidth transducer. The 15BM-1200CA is an upgraded design that features many of P Audio s new technologies & performance upgrades. The 15 inch diameter piston will produce extremely high sound pressure levels at both low & mid band frequencies & is ideal for high level response in both live sound & recorded music venues. The transducer uses high energy ferrite magnetics to achieve a very high acoustic output to weight ratio.
• The 15BM-1200CA has been optimized for use in two way or 3-way sound reinforcement systems. The 15BM-1200CA employs a medium format 3" diameter voice coil that provides an AES rated 300 watts of continuous power handling & a full 1200 watts of peak rated power. The 15BM-1200CA utilizes Auto Balanced Cooling technology to not only improve transducer power handling & reliability but to also increase power compression performance by carefully balancing & directing airflow to critical areas.

Product details

• Brand: P-Audio
• Color: Black
• Model: 15BM1200CA
• Manufacturer: P-Audio
• Item count: 1
• Package quantity: 1
• Warranty: 90 days
