Brand: LM YN
Model: 5824092724
Module nature: Non-isolated boost module.
Input voltage: DC10-32V.
Input current: 5A (MAX).
Static operating current: 15mA (12V to 50V, the higher the output voltage will increase the quiescent current).
Output voltage: ± 45-390V 780V continuously adjustable.
Output power: 40W (peak 70W).
Operating temperature: -40 ~ +75 ℃ (If the ambient temperature is high, please strengthen the heat).
Operating frequency: 75KHz.
Conversion efficiency: up to 88% (efficiency and input, output voltage, current, pressure related).
Short-circuit protection: Yes (input 10A fuse, please do not directly short-circuit the output arc! Direct short-circuit arc may damage the rectifier device).
Overcurrent protection: Yes (input current exceeds 4.5A, lower output voltage).
Overvoltage protection: Yes (output voltage exceeds 410V, lower output voltage).
Input reverse protection: Yes (not self-recovery, then anti-burning fuse, do not reverse.)
Installation: 4 * 3mm screws.
Module size: 60 * 50 * 22mm (length * width * height).
Capacitance charging time measured data:
470uF: Fully charged to 390V for 2 seconds,
1000uF: Fully charged to 390V time 4 seconds,
2200uF: Fully charged to 390V time 8 seconds,
4700uF: Fully charged to 390V for 18 seconds.
Applications:
1, capacitor charging, electromagnetic gun power.
2, for your electronic equipment, power supply, you can set the output voltage with your system voltage.
3, pressure test power supply.
