Brand: Leviton

Amazon.comThe Leviton ODC0S-I1W Ceiling-Mount Self-Contained Occupancy Sensor is the cost-effective choice for commercial and institutional spaces where traditional ceiling-fixture installation is difficult, inconvenient, or costly. Ideal for storage areas, small bathrooms, copy rooms, mop/sink closets, or small spaces without wall switches, this self-contained sensor will help reduce energy costs and it does not require an external power pack and will help reduce energy costs.Automatic Lighting Control for Energy SavingsIt's well-known that turning off the lights when leaving a room is one of the simplest ways to cut down on energy usage. Yet it's not always convenient or easy to remember, especially in rarely used storage spaces or rooms in which a variety of people are coming and going throughout the day.The Leviton ODC0S-I1W Ceiling-Mount Self-Contained Occupancy Sensor helps eliminate this problem by providing automatic motion detection for lighting control. It has an adjustable 360-degree field of view and offers approximately 530 square feet of coverage when mounted at eight feet, reducing the number of sensors required in many spaces. It also offers an adjustable, delayed OFF time setting between 20 seconds and 15 minutes for maximum savings.About PIR TechnologyThe ODC0S-I1W uses Passive Infrared (PIR) detection technology via a segmented Fresnel lens to monitor a room for occupancy. This specialized lens divides the field of view into sensor zones. When a person passes into or out of a sensor zone, the sensor detects motion and switches the lights ON. The lights will remain ON as long as there is an occupant in the room. When the space being monitored by the sensor is unoccupied for the preset time you've entered, the unit will switch the lights OFF.Manual Override and LED Indicator for Easy OperationFor added convenience, the ODC0S-I1W offers an ambient-light override option that can be set between 0.5 and 500+ foot-candles at full brightness to prevent the sensor from switching lights ON when there's sufficient sunlight, regardless of occupancy. A standard A/C toggle may also be used to switch lights OFF during presentations. And to ensure continual operation, an LED indicator flashes when the sensor detects motion to verify power placement and proper functioning of the unit.Compliancy and Warranty InformationUL Listed and CSA certified, the ODC0S-I1W complies with the California Title 24 Energy Code and FCC regulations. It is backed by a five-year limited warranty.What's in the BoxLeviton ODC0S-I1W Ceiling-Mount Self-Contained Occupancy Sensor and manual.Product DescriptionMOTION DETECTOR, SELF-CONTAINED TYPE; 4.3 INCH DIA X 2.15 INCH D SIZE; WHITE FINISH; UL, CSA, CEC, FCC APPROVAL; STORAGE AREA, SMALL BATHROOM, RETROFIT, COPY ROOM, MOP/SINK CLOSET, SMALL SPACE WITHOUT WALL SWITCH APPLICATIONFrom the ManufacturerLeviton's self-contained passive infrared ceiling occupancy sensor is the cost-effective choice for commercial and institutional installations, where installation of the recessed ceiling unit is difficult, inconvenient or costly. Available in 120V, 220V and 277V versions, the ODC0S-I is ideal for storage areas, small bathrooms, copy rooms, mop/sink closets or small spaces without wall switches. The self-contained ceiling sensor does not require an external control unit for power or switching the load on and off. 1000W INC 1000VA FL, 120VAC 60Hz, PIR, 360-degree, 530 sq. ft. coverage, ceiling mount self-contained occupancy sensor, commercial grade - white.

• COST-EFFECTIVE choice for commercial and institutional installations, where installation of the recessed ceiling unit is difficult, inconvenient or costly
• PASSIVE INFRARED TECHNOLOGY -monitors a room for occupancy through a segmented Fresnel lens
• QUICK INSTALL - Sensor and switching relay in one unit-reduces labor and need for additional materials
• SELF-ADJUSTING - delayed OFF time setting between 20 seconds and 15 minutes allows custom adjustment for maximum savings
• ADJUSTABLE LIGHT SENSOR - can be set between 2 and 500+ foot candles and full brightness to prevent the sensor from switching lights ON when ample natural light is available
• 360 DEGREE FIELD-OF-VIEW - with approximately 530 sq. ft. of coverage when mounted at 8 ft. indoor use only
