Brand: INTELLINET NETWORK SOLUTIONS

Add PoE+ capability to a non-PoE switch port with this Gigabit high-power injector. It delivers both data and power over a single Ethernet cable to IEEE 802.3af- and IEEE 802.3at-compliant powered devices, making it suitable for wireless access points, VoIP phones, IP cameras, and other compatible PoE devices. The single output port provides up to 30 watts, with support for cable runs up to 328 ft. This injector features one 10/100/1000 Mbps RJ45 input port and one 10/100/1000 Mbps data-and-power RJ45 output port for Gigabit network performance. It supports IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3af, and 802.3at standards, with IEEE 802.3af/at Mode A pinout on pins 1, 2, 3, and 6. Built-in IEEE 802.3af/at detection helps ensure proper power delivery to compatible devices. Designed for dependable operation, it includes short-circuit protection for short GND, overload protection for currents over 0.6 A, and high-voltage protection. The internal power supply and fanless design support quiet operation. Dual-color LEDs indicate power and PoE status for quick monitoring. The black plastic housing measures 4.37 x 2.24 x 1.3 inches and weighs 0.31 lb. It operates on 100 to 240 V AC, 50 to 60 Hz, with maximum power consumption of 35 watts. Operating temperature range is 32 to 122 degrees F with 5 to 90% RH, non-condensing. Package includes the PoE+ injector, power cable, and instructions.

Features:

• Add PoE+ to a non-PoE LAN switch port with this gigabit injector, which sends both data and power over one Ethernet connection for compatible IEEE 802.3af and 802.3at powered devices such as access points, IP phones, and cameras.
• Single-port PoE+ output delivers up to 30 watts to support devices that need more power while maintaining 10/100/1000 Mbps network speeds, making it suitable for gigabit installations that require both network connectivity and remote power.
• Supports cable runs up to 328 feet, helping place powered devices where they are needed without adding a separate nearby power source
• designed for IEEE 802.3af and 802.3at products including wireless LAN equipment, VoIP phones, and IP cameras.
• Built-in protection features include IEEE 802.3af and 802.3at detection plus safeguards for short circuit, overload, and high voltage conditions, helping protect connected equipment while simplifying PoE deployment on existing Ethernet networks.
• Fanless operation and an internal power supply support quiet installation in offices, retail spaces, and other indoor network environments where low-noise performance matters, while the plastic housing keeps the unit compact and easy to place.
• Equipped with one RJ45 10/100/1000 Mbps input port and one RJ45 10/100/1000 Mbps data-and-power output port, this injector supports gigabit Ethernet over Cat5 and Cat5e cabling for flexible integration into existing copper network runs.
• Compact 4.37 x 2.24 x 1.3 inch housing fits easily into network setups, and the package includes the Gigabit High-Power PoE+ Injector, power cable, and instructions, giving you the core components needed for straightforward installation.

Product Details:

• Color: Black
• Model: 561518
• Package Quantity: 1
