Brand: Honeywell Home

Wireless X-Band DUAL TEC Motion Sensor. Honeywell Home 5898 Wireless X-Band DUAL TEC Motion Sensor provides superior detection and reduces the risk of false alarms. The combination of PIR and X-Band microwave technologies enable the sensors to distinguish between real intruders and other environmental conditions by “confirming” each other within a defined area of protection. The sleek, compact design makes it ideal for applications where aesthetics and discretion are critical. PIR sensitivity and temperature sensing can be enabled via local programming or from the central station. Installation is easy, with no jumpers, switches or disassembly, fewer mounting restrictions and an automatic walk test mode that turns on the LED for ten minutes- saving installers one trip up the ladder for each sensor. The 5898 blends perfectly with Honeywell Home 5800 Series family of sensors to create a seamless look in any residential or light commercial environment. Animal Immune Lens This is not a standalone unit, it requires a security systems to function. Dual Technology Sensor with: Dual Element Passive Infrared X-Band Microwave RANGE 50' x 60' (15m x 18m); 90° wide angle - 44 zones (22 long range, 12 intermediate, 6 lower, 4 look-down) 35' x 40' (11m x 12m); 90° wide angle 102 zones (44 long range, 36 intermediate, 18 lower, 4 look-down) OPERATING TEMPERATURE For indoor use environment: 4°F to 131°F (-20°C to 55°C) RELATIVE HUMIDITY, NON-CONDENSING: 95% max DETECTABLE WALK RATE: 0.7 - 7 ft/Sec. (0.2 - 2.0m/Sec.) TEMPERATURE COMPENSATION: Advanced Dual Slope PET/ANIMAL IMMUNITY: 0, 50 or 100 lbs (0, 22.6, or 45 Kg) When used with the animal immune lens (included) MOUNTING HEIGHT: 7' to 9' (2.1m to 2.7m) TAMPER SWITCH: Front cover and back tamper

• Advanced DualCore Signal Processing DualCore signal processing analyzes PIR and microwave signals through the 5898 microcontroller.
• X-Band Microwave Technology X-Band m custommade source offers pattern shicrowave technology delivers sharp detection without holes or weak spots. Theaping to fill the protected area with a broad, balloon-shape that matches the PIR pattern.
• Faster and Easier to Install Specific features that contribute to this benefit include:
• Automatic walk test - Flashlight walk test - Remotely programmable sensitivity - Circuit board does not need to be removed to install on wall - Ceiling and wall mounting brackets help to easily direct the pattern where needed - No mounting height adjustments
• Hot or Cold Temperature Alert - (< 45° F) warns when temperatures are approaching the freezing point - (> 95° F) warns when temperatures are rising too high
