Description
Brand: eSecure
Resolution: 5MP
Image Size: 2560 x 1936
Video Output: AHD / TVI / CVI
Audio: 1CH built-in MIC
Image System: PAL / NTSC
Electronic Shutter: Auto; 1/50s~1/100000s(P); 1/60s~1/100000s(N)
LED View Distance: 66-98ft (20~30 m)
Frame Rate: 5MP@20fps / 4MP@30fps
Min. Illumination: 0 lux with LED ON
Lens: 3.6 mm
Lens Mount: M12
S/N Ratio: ?52dB (AGC OFF)
Protection Grade: IP67
Smart LED: Yes
Digital WDR: Yes
Digital NR: Yes, 2D DNR
Global Exposure: Yes
Central Exposure: Yes
AGC: Yes
Auto White Balance: Yes
BLC: Yes
Contrast: Yes
Sharpness: Yes
Coaxial Audio: Yes
Image Setting: Yes
Defect Correction: Auto
Language: Chinese/English
Angle Adjustment: Pan: 0°~360°; Tilt: 0°~75°; Rotation: 0°~360°
Power Consumption: LED OFF: <1.5W; LED ON: <3W
Working Environment: -30°C ~ 50°C, 10% ~ 90% RH
Dimensions: ?94.6 x 82.8 mm
Weight: Approx. 0.39 KG
• 5MP @20fps/4MP real-time image, high resolution, true color
• AHD / TVI / CVI lossless high-defintion video output
• CMOS progressive scan, perfectly capturing the moving object, Up to 1500 TVL resolution
• Support OSD menu, Support DWDR
• High speed, long distance and real time transmission
• The LED can be automatically turned on at low illumination
• 66-98ft 20 ~ 30m LED view distance
• Support COC
• Support coaxial audio transmission(Temporarily only valid in TVI signal mode)
• Outdoor IP67 Weatherproof Rating
Camera Specifications:
Image Sensor: 1/2.5" CMOSResolution: 5MP
Image Size: 2560 x 1936
Video Output: AHD / TVI / CVI
Audio: 1CH built-in MIC
Image System: PAL / NTSC
Electronic Shutter: Auto; 1/50s~1/100000s(P); 1/60s~1/100000s(N)
LED View Distance: 66-98ft (20~30 m)
Frame Rate: 5MP@20fps / 4MP@30fps
Min. Illumination: 0 lux with LED ON
Lens: 3.6 mm
Lens Mount: M12
S/N Ratio: ?52dB (AGC OFF)
Protection Grade: IP67
Functions:
Function Control: OSD (COC Control)Smart LED: Yes
Digital WDR: Yes
Digital NR: Yes, 2D DNR
Global Exposure: Yes
Central Exposure: Yes
AGC: Yes
Auto White Balance: Yes
BLC: Yes
Contrast: Yes
Sharpness: Yes
Coaxial Audio: Yes
Image Setting: Yes
Defect Correction: Auto
Language: Chinese/English
Angle Adjustment: Pan: 0°~360°; Tilt: 0°~75°; Rotation: 0°~360°
Other Specifications:
Power Supply: DC12V (±10%)Power Consumption: LED OFF: <1.5W; LED ON: <3W
Working Environment: -30°C ~ 50°C, 10% ~ 90% RH
Dimensions: ?94.6 x 82.8 mm
Weight: Approx. 0.39 KG
• 5MP @20fps/4MP real-time image, high resolution, true color
• AHD / TVI / CVI lossless high-defintion video output
• CMOS progressive scan, perfectly capturing the moving object, Up to 1500 TVL resolution
• Support OSD menu, Support DWDR
• High speed, long distance and real time transmission
• The LED can be automatically turned on at low illumination
• 66-98ft 20 ~ 30m LED view distance
• Support COC
• Support coaxial audio transmission(Temporarily only valid in TVI signal mode)
• Outdoor IP67 Weatherproof Rating
