Brand: COMPUPORT CENTRE INC

<B>Electrical;</B><br> Frequency Range: 600-960/1710-6000MHz<br> Gain : 3/5dBi<br> V.S.W.R: ?2.0?Max:3.5@2700MHz<br> Radiation : Omni-Direction<br> Polarization: Vertical<br> Maximum Input Power : 5W<br> Impedance: 50?<br> Connector : SMA Male<br> Antenna Radome Material: ABS<br> <B>Mechanical</B><br> Dimensions: ?13x152mm<br> Weight: 19g<br> Operating Temperature -40? to+70?<br> RoHS Compliant: YES<br><br> <B>CompuPort Mini Ultra-Wideband 5G 4G LTE Cellular Omni-Directional Antenna</B> is designed to cover a broad frequency range, making it suitable for a wide array of cellular communication applications. Here's a breakdown of its key features and technical specifications:<br> <B>Key Features:</B><br> <B>Ultra-Wideband Design:</B><br> The antenna supports a wide frequency range from 600-960 MHz (low-band) and 1710-6000 MHz (mid to high-band), making it compatible with 4G LTE and 5G networks.<br> It can support 5G, LTE, 4G, 3G, and potentially even older networks depending on the specific use case.<br> <B>Omni-Directional Radiation Pattern:</B><br> This antenna radiates in all directions horizontally, which means it can receive and transmit signals from any direction. This feature is beneficial when you don't know the direction of the signal source, or if you want to provide coverage in all directions.<br> <B>Compact Design:</B><br> The "Mini" in the name suggests that the antenna is relatively small, making it a good option for installations where space is limited, such as on mobile vehicles, rooftops, or in industrial settings.<br> <B>Frequency Range:</B><br> <B>Low Band</B>: 600-960 MHz (commonly used for 4G LTE, 5G sub-1 GHz, and older 3G networks)<br> <B>Mid to High Band</B>: 1710-6000 MHz (includes many 4G LTE and 5G bands, as well as Wi-Fi, and other high-speed cellular services)<br><br> <B>Applications:</B><br> <B>5G and 4G LTE</B>: Suitable for modern mobile networks, including 5G deployments across different bands.<br> <B>Broadband Connectivity</B>: Used in applications like mobile hotspots, M2M (machine-to-machine) communications, and IoT (Internet of Things) devices.<br> <B>Public Safety and First Responders</B>: Can be used in cellular-based emergency communication systems.<br>

Features:

• Experience powerful, reliable connectivity with the CompuPort Mini Ultra-Wideband Antenna. Designed for 5G and 4G LTE networks, this compact omni-directional whip antenna delivers exceptional performance across a wide frequency range of 600-960 MHz and 1710-6000 MHz, ensuring stable communication and maximum data throughput in demanding environments.
• Compact Power, Maximum Coverage. The CompuPort Mini Ultra-Wideband 5G/4G LTE Whip Antenna provides superior signal performance across 600-960 MHz & 1710-6000 MHz, making it the perfect solution for reliable, high-speed connectivity anywhere.
• Supports 5G and 4G LTE networks for global compatibility Omni-directional coverage for consistent signal in any direction. Compact, durable whip design ideal for tight installations. Perfect for: IoT gateways, remote monitoring, industrial routers, and cellular modems
• Enhance your network reliability and speed with the CompuPort Mini Ultra-Wideband 5G/4G LTE Antenna - engineered for performance, efficiency, and seamless connectivity.

Product Details:

• Color: Black
• Size: Small
• Model: CPC-Q6060-YZ152
• Package Quantity: 1
