Brand: BV

The BV-Tech Gigabit PoE+ Injector is a reliable and straightforward solution for powering network devices over a single Ethernet cable, eliminating the need for separate power supplies and reducing cable clutter. Supporting 10/100/1000Base-T Gigabit speeds, it delivers full-speed data transmission alongside power delivery of up to 30W, making it ideal for IP cameras, access points, and VoIP phones. Setup is completely plug and play - simply connect the injector to an AC outlet (100-240V, 50/60Hz), link the uplink port to your router or network switch, and run a single Ethernet cable to your PoE device. Power and data can be transmitted up to 325 feet. Intelligent automatic detection protects non-standard Ethernet terminals and ensures low-power devices receive only the power they require. The PoE port operates at 10/100/1000 Mbps with up to 30W output, while the uplink/data port also supports 10/100/1000 Mbps. The compact design includes integrated wall-mount slots and an interlocking feature for organized multi-unit installations. Backed by a 1-year warranty on parts and labor from the date of purchase.

Features:

• Extended 100-Meter Range: Easily extends both your PoE and Ethernet network range by an additional 100 meters (328 ft.) while maintaining full-rate Gigabit network throughput across the entire extended distance.
• No External Power Supply Needed: Features true plug-and-play functionality that passes data and power over a single Ethernet cable, eliminating the need for a dedicated electrical outlet or external power source.
• 3-Port Gigabit Architecture: Equipped with 3 total Ethernet ports supporting 10/100/1000 Base-T applications, configured as 1 dedicated uplink port and 2 PoE ports sharing a 30W total power budget.
• Intelligent Auto-Sensing Technology: Built with automatic power detection that safely identifies connected equipment, protecting your compatible PoE hardware from being damaged by incorrect installation.
• Universal PoE+ Compliance: Fully compliant with the IEEE 802.3af/at PoE+ standard, making it a cost-effective choice for deploying IP-based surveillance cameras, wireless access points, and IP phones.
• Compact & Wall-Mountable: Offers a space-saving, reliable, and wall-mountable design that ensures a clean, streamlined installation throughout small business or workgroup environments.

Product Details:

• Color: Green,Orange
• Package Quantity: 0
