Brand: ACEIRMC

<p><b><i>Introductions:</i></b></p> <p>for The Addicore nRF24L01 is a 2.4GHz ISM band transceiver. The transceiver consists of a fully integrated frequency synthesizer, a power amplifier, a crystal oscillator, a demodulator, modulator and enhanced ShockBurst, protocol engine.</p> <p>A host microcontroller can communicate and configure the nRF24L01+ over a 4-pin Serial Peripheral Interface (SPI). The configuration registers are accessible through the SPI connection.</p> <p>Configurable parameters include frequency channel (125 selectable channels), output power, and data rate (data rates: 250kbps, 1Mbps, and 2Mbps). The module has 5V tolerant inputs which allows direct connection of SPI pins.</p> <p>Internal filtering results in high margins of meeting RF regulatory standards. The module's radio uses Gaussian Frequency-Shift Keying (GFSK) modulation as well as fast Automatic Gain Control (AGC).</p> <p><b><i>Specification:</i></b></p> <p>Frequence: 2.4GHz~2.5GHz</p> <p>Operating voltage: 3 ~ 3.6V Max</p> <p>Current: 115mA</p> <p>Multi-frequency: 125 frequency</p> <p>Support up to six channels of data reception</p> <p><b><i>Package Included:</i></b></p> <p>5*NRF24L01+PA+LNA Wireless

• The nRF24L01+ is a 2.4GHz ISM band transceiver Compatible with arduino IDE.
• The module has 5V tolerant inputs which allows for direct connection of SPI pins to the compatible with ArduinoIDE.
• Range: 800+ meters line of sight, Weight: 13.28 g (0.468 oz).
• Auto-acknowledge and auto-retransmit abilities.
• In the RF part of a large number of optimized matching debugging, making the highest transmission efficiency, the smallest harmonic, making NRF24L01P + PA + LNA wireless module to external radio equipment to achieve the lowest radio frequency interference, but also not susceptible to interference

Color: Black
