Brand: Hyuduo

Model: ND0412SA(5V)

Specification:
Item Type: Step-up Module
Optional Style: with Pin, without PinOptional Style: 5V, 6V, 9V, 12V
Description:
DC DC Boost Converter Module working frequency 1MHZ.
Up to 93% Efficiency (usually is 84%-91%)
Quiescent current : 190uA.
Current Limit Program(0.5-2.5A,Default 1.8A)
Operating temperature range : -40~+85 Degrees Celsius
Storage temperature range : -65~+150 Degrees Celsius
Size: Approx. 21 x 11 x 4mm / 0.8 x 0.4 x 0.2in(no Pin)
Weight:Approx. 1.3g(no Pin), 1.5g(with Pin)

Protection:
Over current protection(OCP)
Over voltage protection(OVP)
Short circuit protection(SCP)
Over temperature protection(OTP)

Pin description:
Vi:Input positive(+)
GND:Input and Output negative(GND/-)
Vo:Output positive(+)
Output 5V :
Input voltage DC 2.6 ~ 4.5V,output DC 5V±3%
Maximum output : 5V/1300MA(See the table below for details)Measurement results are for reference only

Output 6V:
Input voltage DC 2.6 ~ 5.5V,output DC 6V±3%
Maximum output : 6V/1200MA(See the table below for details)
Measurement results are for reference only

Output 9V :
Input voltage DC 2.6 ~ 5.5V,output DC 9V±3%
Maximum output : 9V/800MA(See the table below for details)
Measurement results are for reference onlyInput VoltageInput CurrentOutput

Output 12V:
Input voltage DC 2.6 ~ 5.5V,output DC 12V±3%
Maximum output : 12V/600MA(See the table below for details)
Measurement results are for reference only

Application Areas:
Battery-powered equipment
Meters and multimeters
Low power motor
PTZ webcam
Web video camera
Toy car ship
Airplane model
power Bank
LED motor
Solar energy
WIFI Router
PLC RS485 device
Lithium battery power equipment

Package List:
2 x DC-DC Step-up Module



• The working frequency of the DC-DC boost converter module is 1MHZ, and the efficiency is as high as 93% and the input voltage is DC2.6-5.5V, output voltage is DC5V / 6V / 9V / 12V.
• The quiescent current is 190uA,operating temperature range is -40~+85 degrees celsius and the storage temperature range is -65~+150 degrees celsius.
• Step-up module adopts high quality electronic components material and accuracy process, ensure for the durability and it has over current protection, over voltage protection, short circuit protection and over temperature protection
• Step-up module has about 21 x 11 x 4mm / 0.8 x 0.4 x 0.2in size and it is Suitable for battery-powered equipment, low power motor and LED motor.
• We strive to provide you with the highest quality product and the best customer experience, if you're not entirely satisfied, please just feel free to contact us at any time.
